Experience Automation in 3D

3D Smart Dashboard Plan – Immersive Control, Real-World Visualization

Introduction

As smart environments grow more complex, 3D dashboards bring a new level of clarity and immersion to automation control. Our 3D Dashboard Plan transforms traditional flat dashboards into interactive, spatially accurate 3D environments, allowing users to visualize, monitor, and control devices exactly where they exist in the real world.

This approach bridges the gap between physical spaces and digital control, making automation intuitive for homes, hotels, hospitals, offices, and commercial buildings.

What is a 3D Dashboard?

A 3D dashboard is an advanced visualization layer built on top of automation systems, where rooms, floors, and devices are represented in a 3D model. Users can interact with lights, switches, curtains, HVAC, security, and media systems directly within a virtual space that mirrors the real building.

Instead of guessing which device belongs to which room, users simply tap the room or object in the 3D view.

Key Features of Our 3D Dashboard Plan

🏠 Realistic 3D Floor Plans

• Full 3D models of homes, villas, hotels, hospitals, and offices

• Multi-floor navigation with zoom, rotate, and pan

• Accurate placement of devices inside rooms

🎛 Interactive Device Control

• Click on lights, fans, ACs, curtains, locks, TVs, and sensors

• Context-aware controls (slider, toggle, scene, remote UI)

• Visual state changes (ON/OFF, dim level, open/close)

🔗 Automation System Integration

• Seamless integration with Home Assistant

• Entity-based mapping between 3D objects and automation devices

• Real-time updates via WebSocket or API

🧠 Smart Scenes & Automations

• Scene visualization (Movie Mode, Night Mode, Away Mode)

• Time-based and event-based automation previews

• Zone-level and room-level control

🧩 Drag-and-Drop Configuration

• Assign devices to 3D objects visually

• No complex coding required

• Admin-friendly configuration panel

📱 Cross-Platform Access

• Works on desktop, wall panels, tablets, and kiosks

• Optimized performance for touch screens

• Optional VR/AR-ready expansion

Use Cases

🏡 Smart Homes & Villas

• Natural control for non-technical users

• Family-friendly visualization

• Premium experience for luxury homes

🏨 Hotels & Hospitality

• Room-level dashboards for guests

• Staff dashboards for maintenance and monitoring

• Faster issue detection and service response

🏥 Hospitals & Healthcare

• Ward and room monitoring

• Equipment status visualization

• Energy and safety awareness

🏢 Offices & Commercial Buildings

• Floor-wise energy monitoring

• Centralized control rooms

• Smart meeting room management
